Feature:

1. Faster diagnostics operation system: equipment leading the ARM chip.

2. Fast and stable system applications: advanced and comprehensive diagnostic software management platform.

3. 8-inch high resolution touch screen, colour fidelity, visual and more comfortable operation.

4. Built-in high-performance, overvoltage protection circuit, to improve product reliability.

5. Storage and playback of test data and pictures

6. Bluetooth VCI Diagnostic box: Host and run independently of the VCI box, built-in Bluetooth module, the wireless communication. Supports both wired communications, the use of flexible.

7.Unique VCI self-test function.

8.On-board mini printer. Print out the diagnosis result and show to your customer right way without bothering to connect to PC.

9.Frequent update via Internet.

Function:

1. Auto key programming/immobilizer

2. Oil reset

3. Reads /erases fault codes

4. Scans engine

5. Turns off service lights

6. Scans auto transmission

7. Turns off SRS airbag lights

8. Turns off ABS lights

9. Live data stream

Special functions:

I. Key programming

II. Oil reset

1. Key programming:

* New keys programming

* Reads keys from immobilizer’s memory

* New immobilizer programming

* New ECU programming

* New mechanical key number programming

* Vehicle Identification Number programming

* Reset ECM & reset immobilizer

* Easy to operate by the guided menu programming

* New remote controller programming

* With full and strong database for the most important vehicle makes

Key programming supports the following models:

Volkswagen, Audi,for Honda, Kia, for Buick, for Chevrolet, Dongfeng, Citroen, for Peugeot, Mazda, Brilliance China, Brilliance Jinbei, Chery, Changan, the Great Wall, Changan, Changhe, Dongfeng fashion, Hafei, hippocampus, maple, Changfeng, Liebao, JAC, Geely, Lifan, breeze, Zhengzhou Mazda, for Nissan, Zhengzhou for Nissan, FAW, Tianjin FAW Besturn, SAIC England, BYD ( test ), Changan for Ford ect.

2. Oil reset

* Oil Reset/Engine oil light reset
* Tire pressure warning light reset (manual operation)
* Timing belt light reset (manual operation)
* OBD-II engine diagnosis
* EPB Electronic Brake changes brake pad
* Throttle matching (for GM, for Honda, for Nissan, Acura)
* Support the latest vehicles with CAN BUS and UDS

Application list:

PS: VW, Audi (One click. No need to input any channel number)

The replacement of EPB brake pad supports for the following models:
VW ( R36, CC, Magotan etc.)
Audi ( A4L, A6L, Q5 etc.)
Seat
Skoda

Tire pressure warning light reset (manual operation)
VW
for BMW

Diagnose Vehicle List:

Japan: for Honda, Mazda, Mitsubishi, for Nissan, for Subaru, Suzuki, Toyota, Daihatsu, Isuzu

Europe: VW, For Audi, SEAT, SKODA, for Mercedes Benz,for BMW, Citroen, Europe Ford, Fiat, Opel, for Peugeot, For Renault, for Volvo

India: Mahindra, MARUTI, TATA

America: America for Ford, Chrysler, for GM, ACRUA

Australia: Australia For Ford, Holden

Brazil: Brazil OPEL

China: DFSK

Korea: Hyundai, Kia, Ssangyong

Malaysia: Perodua, Proton

Specification:

Operating system: WINCE5.0 operating platforms
CPU: SAMSUNG ARM9 2410A, 200MHz

Wireless communication: Bluetooth

Bluetooth: 0 to 100 meter

Temperature: -20-50
Relative humidity: <90%

Memory: SDRAM 64M
Flash Card: 2 GB
Mainframe power supply: DC12V, AC 100~240V 50-60Hz

Mainframe battery: rechargeable battery 3500m/Ah
Mainframe power: 25W

Printer: Mini high-speed thermal sensitive printer
Screen: 8 inches real-color touch-screens, 800*600 with LED back-light

Package Dimension: 548*408*164mm

Weight: 5 KG
