inverter for auto cars

inverter for auto cars
Categoriesmanage1
BrandATLI
ModelATIP-1500W
Output Power1500W
Output TypeSingle
Size225*135*57mm
Weight2.45kg
Input VoltageDC12V/24V/48Vand others are avai...
Output Voltage100,110,220,230,240V AC are sta
TypeDC/AC Inverters
Output Frequency50Hz/60Hz
Output Currentby load
Unit PriceUS $ 20-150 / piece
Update Time2022/5/22
Detail Information

Product Features:

1.Low voltage input model adopt original imported IR MOS tube.The current is 5.5 times of rated current.

2.It low voltage input connection adopt high frequency low resistivity electrolytic capacitor. However ordinary capacitor will explode if the temperature become very high.

3.Every transformer has independent fuse protection.If there is a MOS tube break down,then the fuse will break fast.So that will not effect other MOS tube to break.

4.All the protection signal adopt monolithic processing.Circuit is simple and stable.

5.Input and output are isolated to ensure the operation stability

6.Output circuit adopt convertible circuit.The SPWM signal produced by Single Chip Microcomputer drive the A3120 optical coupler.Then the optical coupler isolated drive the output through IGBT tube.Adopt negative pressure to cut off IGBT to eliminate Miller effect,so the output is more steady.

7.The whole design adopt patch technology.The circuit is simple and steady.

8.Optional remote ON/OFF control switch;

9.Smart protection function with LED and alarm show.

 inverter for auto cars



Parameter



Model  I-P-PPI-800W I-P-PPI-800W+R
Remote controlNOYES
Rated output capacity600W
Peak power1200W
Input                                           DC 12V /DC 24V / DC 48V DC 12V
Output VoltageAC100V~120V or 200V~240V
 Frequency50Hz or 60Hz
 WaveformPure Sine Wave
 RegulationVrms <±5%
 Efficiency>85%
 Total Harmonic DistortionTHD <3%
 USB OutputDC 5V±5% 500mA
Protection Voltage/CurrentLow Battery AlarmDC 12V/10.5V ; DC 24V/21V ; DC 48V/42VDC 12V/10.5V
 Low Battery Shut DownDC 12V/10V ; DC 24V/20V ; DC 48V/40VDC 12V/10V
 High Battery ProtectionDC 12V/15V ; DC 24V/30V ;DC 48V/60VDC 12V/15V
 No Load Current12V / 400mA24V / 200mA48V / 100mA12V / 400mA

Intelligent Design

Heat Auto Control

Fan Start : 42°C±3 ,  Fan Stop : 38°C±3
 High Temperature Shut Down : 63°C±3 ,  Restart Output : 55°C±3
Indicate and alarm signalIndicatorInverter: Green LED ; Fault: Red LED ; Over Temperature: Yellow LED
 Low Battery AlarmAlarm sounds:BiBi~BiBi~
 Low/High Voltage alarm Alarm sounds:BiBi~
 Over Temperature protectionAlarm sounds: Bi~; LED indicate: Yellow


Over Loaded protection;

short circuit protection

Alarm sounds: BiBiBi~~; LED indicate: Red
Physical StateSize W×D×H(mm)(225+25)*157*75
 Packing size W×D×H(mm)  295*203*90
 Net weight (kg)  2.6
 Gross weight (kg)2.9
